The HL760 features a digital readout of elevation that provides a numeric display of ± 2 inches (± 5 cm). The readout is displayed on the large front and rear LCD’s and shows exactly how far the elevation is from on-grade for fast and easy cut/fill readings. Accurate measurements can be made without moving the rod clamp, saving time and increasing productivity. Selectable units of measure can be displayed meeting your application - mm, cm, ft, in or fractional inches. A  5 inch (12.7 cm) reception height, more than double the industry standard, allows quick acquisition of the laser beam. An anti-strobe sensor prevents false readings from site strobe lights. Radio communication allows working with another HL760U or HL760 for long range remote display and monitoring capability. A new function termed “Fingerprinting” links the receiver with a particular laser. Once the receiver is paired with the laser transmitter, the receiver has the ability to filter out other lasers that strike the receiver and only accept the laser that it is paired with. The HL760U also provides grade matching and PlaneLok capabilities with the 400 series lasers. The HL760 receiver includes an LCD backlight so the digital readout and other receiver information is visible in low light and dark conditions. The Digital Readout Receiver is designed to survive the tough construction site conditions; it is totally waterproof and can withstand a drop of 10 feet (3 meters) onto concrete. The HL760 offers a 3-year “No Excuses” warranty.

  • Digital readout of elevation – not only will high or low arrows be displayed, but the exact distance from grade will be displayed, which eliminates the need to get “on-grade” to make measurements
  • Large 5 inch (12.7 cm) reception height acquires the beam quickly and makes it easy to stay in the beam
  • The HL760 has an internal, long range 330 ft (100m) radius, high speed digital radio built inside that allows the receiver to communicate with any other HL760 / HL760U: LL300S, LL400HV, HV302, GL412N / GL422N laser transmitters
  • Machine operators can monitor elevation shots taken by another person or foremen can monitor elevations and cut/fill readings from anywhere on the jobsite
  • Anti-strobe sensor stops construction strobe lights from setting off the receiver, and makes it easier to identify true laser beam signals
  • Multiple deadband setting allows adaptation to meet all your jobsite requirements
  • Dust and weatherproof housing withstands a drop of up to 10 ft (3 m) onto concrete for reduced downtime
  • Two clamp positions for cut/fill or excavation
  • Three-year “No Excuses” warranty
  • C70 Clamp with Bubble Vial included
  • Clamp comes with patented reversible jaw to allow a more solid fix to round or square rods
  • When working in deep excavations the capture mode allows the user to pick up the laser elevation without having to adjust the receiver to the on-grade position it tells you how far off on-grade you are.

Spectra HL760 Laser Level Receiver

SKU: 202801600166
$295.00Price
    • Digital readout of elevation – not only will high or low arrows be displayed, but the exact distance from grade will be displayed, which eliminates the need to get “on-grade” to make measurements
    • Large 5 inch (12.7 cm) reception height acquires the beam quickly and makes it easy to stay in the beam
    • The HL760 has an internal, long range 330 ft (100m) radius, high speed digital radio built inside that allows the receiver to communicate with any other HL760 / HL760U: LL300S, LL400HV, HV302, GL412N / GL422N laser transmitters
    • Machine operators can monitor elevation shots taken by another person or foremen can monitor elevations and cut/fill readings from anywhere on the jobsite
    • Anti-strobe sensor stops construction strobe lights from setting off the receiver, and makes it easier to identify true laser beam signals
    • Multiple deadband setting allows adaptation to meet all your jobsite requirements
    • Dust and weatherproof housing withstands a drop of up to 10 ft (3 m) onto concrete for reduced downtime
    • Two clamp positions for cut/fill or excavation
    • Three-year “No Excuses” warranty
    • C70 Clamp with Bubble Vial included
    • Clamp comes with patented reversible jaw to allow a more solid fix to round or square rods
    • When working in deep excavations the capture mode allows the user to pick up the laser elevation without having to adjust the receiver to the on-grade position it tells you how far off on-grade you are.
